商品の詳細:

ブランド名: Commscope
モデル番号: PC-C6AU-LSB1-WH-2M
書類: PC-C6AU-LSB1-WH .pdf

お支払配送条件:

最小注文数量: 1個
価格: Negotiate
パッケージの詳細:
受渡し時間: 備蓄に基づいた
支払条件: T/T
供給の能力: プロジェクト/バッチによる供給
ベストプライス 連絡先

詳細情報

ANSI/TIAクラス: 6A ケーブルタイプ: U/UTP (保護されていない)
タイプのコンダクター: 堅いワイヤー インターフェース、コネクタA: RJ45プラグ
インターフェースの特性: 標準 コネクタAインターフェース: RJ45プラグ
長さ: 2m
ハイライト:

28AWG Cat 6A Patch Cord

,

2M Length Ethernet Cable

,

500 MHz Network Cable

製品の説明

CommScope CAT6A 28AWG U/UTP LSZH Network Patch Cord

Next-Generation High-Density Connectivity for Demanding Network Environments

Ultra-Slim Profile

28AWG construction with 5.2mm diameter enables superior cable management and increased port density in crowded network

Advanced Network Connectivity Solution

The CommScope CAT6A 28AWG U/UTP LSZH patch cord represents a significant advancement in network infrastructure technology. This high-performance networking cable combines cutting-edge materials engineering with precision manufacturing to deliver exceptional reliability in the most demanding environments.

Designed for IT professionals and network engineers, this Ethernet cord provides the perfect balance of performance, safety, and space efficiency. The innovative 28AWG design allows for unprecedented density while maintaining full CAT6A transmission capabilities.

Technical Specifications

Parameter Specification Standard/Value
Performance Standards Transmission Category ANSI/TIA-568.2-D CAT6A, ISO/IEC 11801 Class EA
Physical Construction Conductor Specification 28AWG Stranded Copper, U/UTP Design

Cable Diameter 5.2mm Ultra-Slim Profile
Connector System Interface Type 8P8C RJ45, T568B Configuration

Durability Rating 750+ Insertion Cycles Minimum
Environmental Specs Operating Range -10°C to +60°C Temperature

Safety Compliance LSZH Jacket, GB/T 31247 B1

Application Environments
